This 5 inch TFT display with touch function is a mini panel-mountable HDMI monitor. It's small and simple, and the shape makes it easy to attach to a electronic product. The touch screen resolution is 800x480 and it has large view angle. It is not only work with raspberry pi, also can work with all HDMI device, but the touch function just for raspbian and Ubuntu systems.
Features:
A good solution for those seeking for a bigger resolution display
Designed for Raspberry Pi, an ideal alternative solution for monitor
800×480 resolution, better display
Good touch response
Large viewing angle
Fast response time
For Raspberry Pi B+/2B Raspberry Pi 3B
With detail tutorial
Specifications:
5 inch TFT Resistive touch screen display, 800x480 Resolution
HDMI input
Usb touch and power, 5V
Lcd driver IC: ILI9486L
Refresh rate：60HZ
Lcd Size ：120mm*78mm
Package list:
5 inch Touch LCD Display x1
HDMI connector x1
Touch pen x1
Protective case x1

Technical Specification: - 7" Touchscreen Display. - Screen Dimensions: 194mm x 110mm x 20mm (including standoffs) - Viewable screen size: 155mm x 86mm - Screen Resolution 800 x 480 pixels - 10 finger capacitive touch. - Connects to the Raspberry Pi board using a ribbon cable connected to the DSI port. - Adapter board is used to power the display and convert the parallel signals from the display to the serial (DSI) port on the Raspberry Pi. N.B. Will require the latest version of Raspbian OS to operate correctly. Features: The 7" Touchscreen Monitor for Raspberry Pi gives users the ability to create all-in-one, integrated projects such as tablets, infotainment systems and embedded projects.The 800 x 480 display connects via an adapter board which handles power and signal conversion. Only two connections to the Pi are required; power from the Pi's GPIO port and a ribbon cable that connects to the DSI port present on all Raspberry Pi's.Touchscreen drivers with support for 10-finger touch and an on-screen keyboard will be integrated into the latest Raspbian OS for full functionality without a physical keyboard or mouse. Kit Contents: - 7" Touchscreen Display - Adapter Board - DSI Ribbon cable - 4 x stand-offs and screws (used to mount the adapter board and Raspberry Pi board to the back of the display - 4 x jumper wires (used to connect the power from the Adapter Board and the GPIO pins on the Pi so the 2Amp power is shared across both units)

1024×600, 7 inch Capacitive Touch Screen LCD, HDMI interface, supports various systems

7inch HDMI LCD (C) Features

• Latest Version -IPS screen, wider viewing angle, more clear displaying, better touch effects, stronger anti-interference ability.
• Standard HID protocol, easy to be integrated into your system
• Adding the VCOM adjustable resistance and EMC circuit
• For the Raspberry Pi, supports Raspbian, Ubuntu, single touch, and driver free
• When work as a computer monitor, supports Windows 10/8.1/8/7, five-points touch, and driver free
• Supports Raspberry Pi
• Supports Banana Pi / Banana Pro, comes with Lubuntu, Raspbian images
• Supports BB Black, comes with Angstrom image
• Backlight can be turned off to lower power consumption

Note: to use the LCD with following mini-PCs, additional cables are required and should be purchased separately:

Raspberry Pi Zero: HDMI cable;USB-type-A-receptacle-to-Micro-B-plug-cable

BB Black: HDMI cable

Development Resources

Wiki : www.waveshare.com/wiki/7inch_HDMI_LCD_ (C)?Amazon

Note

1.If the LCD flickering or has ghost problem , please check if the config file was configured correctly. Or adjust the potentiometer on the backside , and after the screen can display the desktop, rotate the resistor until it can get the best display of desktop.Then please leave the screen for a while,waiting for the ghost to disappear (may take several hours)

2. if there are some red lines on the edge of the screen,please adjust the config.txt file by adding [hdmi_drive=1] into the end of code.After that please power off the screen and put it aside for a few hours to avoid the flickers.

Caratteristiche

IPS, 1280×800, 10.1 inch Capacitive Touch Screen LCD, Supports Multi mini-PCs, Multi Systems, Comes with EU plug power adapter

Description
1. IPS screen,1280×800 high resolution
2. Capacitive touch control, supports up to ten-points touch
3. When works with Raspberry Pi, supports Raspbian, Ubuntu, single touch, and driver free
4. When work as a computer monitor, supports Windows 10/8.1/8/7, ten-points touch, and driver free
5. Supports Banana Pi, Banana Pro, comes with Lubuntu, Raspbian images
6. Supports BB Black, comes with Angstrom image
7. HDMI interface for displaying, USB interface for touch control
8. Supports 5-level backlight adjustment

Note: to use the LCD with following mini-PCs, additional cables are required and should be purchased separately:
Raspberry Pi Zero: HDMI cable, USB-type-A-receptacle-to-Micro-B-plug-cable
BB Black: HDMI cable

The Case
Material : high quality black Acrylic
Comes with back holder, 45° tilt angle
Features mounting holes for Raspberry Pi 3B+/3B/2B/B+/A+/B, BB Black, Banana Pi

Package Content
10.1inch HDMI LCD (B) (with case) x 1
Back holder x 1
Spare screws x 1
HDMI cable x 1
USB type A plug to micro B plug cable x1
Power adapter EU standard USB output x1

Features

• 7inch IPS screen, capacitive touch screen LCD with toughened glass cover, 1024x600 hardware resolution, configurable by software (up to 1920x1080), displaying with high resolution picture, large viewing angle
• Toughened glass capacitive touch panel, 6H hardness;High quality PC case, optional tilt angle: 30°/50°

• Supports popular mini PCs such as Raspberry Pi,Jetson Nano,BB Black, Banana Pi, as well as general desktop computers ;
• When works with Raspberry Pi, supports Raspbian/Ubuntu/Kali/Retropie/WIN10 IOT, driver free

• When work as a computer monitor, supports Windows 10/8.1/8/7, five-points touch, and driver free
• Multi languages OSD menu, for power management, brightness/contrast adjustment, etc.
• 3.5mm audio jack, supports HDMI audio output
• Also supports VGA input (specific cable is required and should be purchased separately)

Development Resources

Wiki : www.waveshare.com/wiki/7inch_HDMI_LCD_(H)_(with_case)?Amazon

FAQ

1.What is the operating current of 7inch HDMI LCD (H)?

With 5V power input, it is about 750~850mA

2.Why the LCD doesn't work with my Raspbian?

To use the LCD with the Raspberry Pi official image, driver should be installed first. Please refer to the user manual.However, for the first testing, you may want to use our provided image directly.

Package Content

1. 7inch HDMI LCD (H) (with case) x1
2. HDMI cable x1
3. USB type A plug to micro B plug cable x1
4. Quick start sheet x1

Note:Detailed tutorials and information can be offered for free, contact us by email via Amazon to receive documents.

Si prega di notare che la porta HDMI sul Raspberry Pi non è accessibile con questa custodia. Il tocco smartipi è un recente successo kickstarter. Il design ultra sottile permette la massima versatilità di montaggio per i quasi ovunque. La custodia può essere facilmente regolato ad ogni angolo. Piccoli supporti in metallo sono inclusi anche che permettono di creare un ingombro minimo e si attaccano alle pareti o qualsiasi superficie. Il caso funziona anche con Raspberry Pi Hat Boards. Questo caso ha versione LEGO compatibili con borchie sul davanti. Offriamo anche un' altra versione che non dispongono di LEGO compatibili con borchie sulla parte frontale del case. La dotazione LEGO compatibile per fotocamera funziona con Pi fotocamera versioni 1 e 2. La custodia include anche una scheda micro USB cavo splitter che puoi utilizzare per alimentare il display e Raspberry Pi allo stesso tempo. Il caso è realizzato in plastica ABS resistente. Disclaimer: LEGO® è un marchio registrato del gruppo di società LEGO. Questo prodotto non è sponsorizzato dal gruppo LEGO con licenza o di società.Raspberry Pi e display ufficiale Raspberry Pi non incluso.

Nota: Raspberry Pi non incluso!

Progettato SPECIALE per Raspberry Pi 3 Modello B; Pieno accesso a tutti i controlli e funzionalità
La custodia protettiva è composta da un involucro in PMMA a cinque pezzi che si incastra perfettamente attorno al modello B di Raspberry Pi 3, offre la migliore protezione / accessibilità disponibile per il modello B, protegge e protegge il tuo Raspberry Pi da urti, graffi e polvere.

Descrizione:
Tipo LCD: TFT
Interfaccia LCD: SPI (supporta un ingresso SPI fino a 125 MHz)
Touch Screen Type: Resistivo
Controller Touch Screen: XPT2046
Risoluzione: 320 * 480 (Pixel)
consumo di energia: 120ma
Temperatura di esercizio (℃): -20 ~ 70

Il pacchetto include: 1 schermo da 3,5 pollici
1 x Custodia protettiva
1 x penna touch
2 x dissipatori di calore
1 x dissipatore di calore in rame
1 x cacciavite
1x set di viti per l'installazione della ventola di raffreddamento
1x 4 pezzi di piedini in gomma
1 x istruzione
1 x schermo opaco
