sunfounder 7 lcd monitor

Technical Specification: - 7" Touchscreen Display. - Screen Dimensions: 194mm x 110mm x 20mm (including standoffs) - Viewable screen size: 155mm x 86mm - Screen Resolution 800 x 480 pixels - 10 finger capacitive touch. - Connects to the Raspberry Pi board using a ribbon cable connected to the DSI port. - Adapter board is used to power the display and convert the parallel signals from the display to the serial (DSI) port on the Raspberry Pi. N.B. Will require the latest version of Raspbian OS to operate correctly. Features: The 7" Touchscreen Monitor for Raspberry Pi gives users the ability to create all-in-one, integrated projects such as tablets, infotainment systems and embedded projects.The 800 x 480 display connects via an adapter board which handles power and signal conversion. Only two connections to the Pi are required; power from the Pi's GPIO port and a ribbon cable that connects to the DSI port present on all Raspberry Pi's.Touchscreen drivers with support for 10-finger touch and an on-screen keyboard will be integrated into the latest Raspbian OS for full functionality without a physical keyboard or mouse. Kit Contents: - 7" Touchscreen Display - Adapter Board - DSI Ribbon cable - 4 x stand-offs and screws (used to mount the adapter board and Raspberry Pi board to the back of the display - 4 x jumper wires (used to connect the power from the Adapter Board and the GPIO pins on the Pi so the 2Amp power is shared across both units)

PACKAGE CONTENT
7inch HDMI LCD (C) x 1
HDMI cable x 1
USB type A plug to micro B plug cable x 1
RPi screws pack (4pcs) x 1

Rev2.1 Feature
Upgrade to IPS screen, wider viewing angle, more clear displaying
Standard HID protocol, easy to be integrated into your system
For the Raspberry Pi, supports Raspbian, Ubuntu, single touch, and driver free
When work as a computer monitor, supports Windows 10/8.1/8/7, five-points touch, and driver free
Supports Raspberry Pi
Supports Banana Pi / Banana Pro, comes with Lubuntu, Raspbian images
Supports BB Black, comes with Angstrom image
Backlight can be turned off to lower power consumption

Why the LCD still doesn't work with the provided image?
Make sure the hardware connection is correct and connects fine.
Make sure the image in TF card is burnt correctly.
The PWR will keep on and the ACT will keep blinking when the Raspberry Pi starts up successfully, in case both of the two LEDs keep on, it is possible that the image was burnt incorrectly OR the TF card was in bad contact.

Which power supply should I use?
It is strongly recommended to use a stand-alone 5V/2A power adapter, because the PC's USB port might have not enough power to support the Pi and LCD.

Specifications
-Screen size: 7 inch Display
-Ration: 16:9/4:3 adjustable
-Display Component: Color TFT-L
-Resolution: 1024*600 Pixels
-Support adjust the brightness, contrast, color
-Input Signal: PC(VGA),AV1,AV2,HDMI
-Power: DC 12V
-Consumption: 6W
-Video: two way video input
-Frequency: PAL/NTSC
-Rear watching: image can be changed left and right
-Operate mode: the key operation and remote control
-Automatically displays blue screen when no signal
-Parking rearview priority
-Product Dimensions: 174*114*33mm (L*W*D)

Package include (HDMI cable is NOT included)
1* 7 inch TFT LCD Screen
1* IR remote controller
1* 12V 1A Power supply
1* power cable
1* rotatory stand
1* adhesive tape

Introduction
This SunFounder Touch Screen is a 10-point IPS touch screen in a 10.1'' big size and with a high resolution of 1280x800, bringing you perfect visual experience. It works with various operating systems including Raspbian, Ubuntu, Ubuntu Mate, Windows, Android, and Chrome OS.
For more information, please refer to: http://wiki.sunfounder.cc/index.php?title=10.1_Inch_Touch_Screen_for_Raspberry_Pi

Package Included
1 x 10.1'' IPS Touch Screen
7 x M2.5 x 14.4 Copper Standoff
2 x M2.5 x 22 Copper Standoff
2 x Wrenches
1 x HDMI Cable
1 x MicroUSBCable
1 x USB Touch Screen Cable
1 x 12V2A Power Adapter
